About Bio-Based Biodegradable BiONLY® BOPLA Control Panel Film
Bio Based Biodegradable BOPLA film for Control Panel is a highly advanced biaxially oriented polylactic acid (BOPLA) film that uses all-renewable plant-based materials. BiONLY is designed for premium interface applications and sustainable packaging of electronics; this BOPLA film provides the highest level of mechanical and optical performance available from environmentally-responsible materials. The low-carbon material represents an optimal option for use as an overlay material on switches and panels, and for protecting the products inside with eco-friendly packaging films.
Bio Based Biodegradable BOPLA film for Control Panel was engineered to deliver top-notch performance for both its aesthetic value and its durability. Bio Based Biodegradable BOPLA film for Control Panel's superior stiffness, strength and dimensional stability allows it to maintain a high-quality appearance. Additionally, BiONLY has superior optical properties, including high gloss, high transparency, and low haze. Therefore, finished products such as switch covers and wall plates will continue to have their premium look after being packaged using sustainable methods. BiONLY can be used as a switch overlay material or as a high-strength, eco-friendly packaging film for electronics to enhance both product protection and brand image.
The bio-based biaxially oriented PLA film of BiONLY supports companies’ efforts to reduce their carbon footprint by comparison to traditional petroleum-based plastics. When industrially composted, BiONLY biodegrades into carbon dioxide (CO2), water (H2O), and biomass through microbial activity. BiONLY also meets key biodegradable standards across the European Union, the U.S., and India, enabling manufacturers to satisfy international environmental regulations and sustainability objectives.
Bio Based Biodegradable BOPLA film for Control Panel is a smart and responsible packaging solution for the electrical industry and housing industries to create sustainable packaging solutions for switches and switch wall plates. It enables companies to associate their packaging with current green building trends and with eco-conscious consumers' expectations of sustainable packaging without compromising on performance, protection, or aesthetic appeal. Companies may illustrate environmental stewardship and the premium quality expected by their customers when they choose Bio Based Biodegradable BOPLA film for the control panel.
| Thickness μm | Corona | Width mm |
| 20 - 40 | Single Side | 300-1300 |
Basic Info.
| Model NO. | ESL-112 | Thickness | 20-40 |
| Transport Package | Carton Package | Specification | ESL |
| Trademark | Changsu | Origin | China |
Product Description
100% Bio-based, biodegradable & compostable flexible film
Product Features
1. Biodegradable & Bio-Base Materials
BiONLY® BOPLA film is produced from sustainable agricultural feedstock such as corn or sugarcane, which results in less reliance on petrochemicals such as BOPP/PET. This results in an enhanced ESG performance for Electrical Accessory Manufacturers and supports both green building certifications and eco-friendly product positioning.
2. Reduced Carbon Footprint
BiONLY® BOPLA film generally produces a lower carbon footprint compared to the conventional use of petrochemical-based films. As a result, BiONLY® BOPLA film is becoming an increasingly popular option among manufacturers providing products to construction, interior design, and smart home industries, where claims of being environmentally sustainable carry importance.
3. Excellent Clarity & Gloss
Control Panels and Light Switches are examples of products where aesthetics play a significant role. BiONLY® BOPLA film provides excellent clarity and surface gloss so that:
* Colour and finish of the product are clearly visible
* Premium Retail Presentation
* Branded Graphics and printed images
4. Excellent Mechanical Properties
BiONLY® BOPLA film provides:
* Tensile Strength
* Stiffness
* Dimensional Stability
As a result, BiONLY® BOPLA film protects delicate electronic surfaces from scratches and dust by ensuring packaging integrity throughout transportation and storage.
5. Excellent Printability
Flexographic, Gravure, Digital Printing and other methods produce high-quality prints on the smooth surface of BiONLY® BOPLA film, making it perfect for:
* Branded Logos
* Instructional information
* Warning Symbols
* QR Codes
6. Provides Scratches & Surface Protection
Surface protection of glossy Control Panels and Decorative Wall Covers is critical. BiONLY® BOPLA film may be utilised as:
* Protective Over Wrap Film
* Protective Layer for Surface
* Pouch and Bag Printed Stock
BoPLA film protects against minor abrasions during shipping.
7. Compatible with Pressure Sensitive Label Adhesive Systems
When used as a Label Stock or Over Laminate Film, BiONLY® BOPLA film functions well with Pressure Sensitive Adhesive Systems, allowing for:
* Identification Labels
* Barcode Labels
* Certification Markings
8. Assists Green Building & Smart Home Branding
Electrical and wall-mounted products are increasingly promoted as:
* Smart Home Solutions
* Energy Efficient Systems
* Sustainable Construction
Utilising Bio-Based Packaging reinforces the overall Sustainability Story.
9. Lightweight & Efficient
Due to its low density, BOPLA film reduces:
* Weight of Packaging
* CO2 Emissions associated with Transportation
* Use of Materials
10. Industrial Composting Capability
When total packaging systems are properly designed (using compatible adhesives and inks), BOPLA can be industrially composted — supporting eco-conscious waste management systems.
Key Technical Considerations for Control Panels and Electrical Accessories
To protect sensitive electronics, control panels and electrical accessories, make sure to:
* Apply anti-static treatment when necessary
* Select proper heat-resistant level (BOPLA has lower heat resistance than PET/BOPP)
* Choose appropriate thickness levels for mechanical protection
* Meet all applicable local packaging regulations for electrical devices
Product Parameters
| Typical Properties | Test Method | Units | Typical Value | |
| Thickness | - | μm | 40 | |
| Average Thickness Tolerance | ISO4593 | % | ±3.0 | |
| Tensile Strength | MD | ASTM D882 | MPa | 120 |
| TD | 120 | |||
| Elogation at Break | MD | ASTM D882 | % | 120 |
| TD | 125 | |||
| Heat Shrinkage | MD | ASTM D1204 (100ºC, 10min) | % | 4 |
| TD | 1.8 | |||
| Dynamic COF | Untreated Side/ Untreated Side | ASTM D1894 | - | - |
| Surface Tension | Treated Side | ASTM D2578 | mN/m | 42 |
| Untreated Side | - | |||
| Haze | ASTM D1003 | % | 2.5 | |
| Light Transmission | 94 | |||
| Gloss (angle 45°) | ASTM D2457 | % | - | |
| Heat Seal Strength | 135Kpa/85℃/2s | N/15mm | 5.0 | |
Length (m): Standard 2500 or 5000
With(mm): 300-1300
Paper core (inches): 3, 6
Remark:
1. Testing Conditions: 20°C, 65% RH (except as otherwise provided in the test method)
2. The property values contained in the table represent neither product specifications nor typical/average values.
Frequently Asked Questions (FAQ) about BiONLY® BOPLA – Eco-Friendly Packaging Film
Q: What percentage of bio-based carbon is found in the BiONLY® BOPLA film?
A: BiONLY® BOPLA is a biaxially oriented PLA film created using renewable sources such as sugarcane, straw and other plant based materials. As such, the bio-based composition makes it a good candidate for use as an eco-friendly electronic packaging film for switch socket packaging, switch wall plate packaging, etc.
Q: Will I have to purchase new equipment for the switch socket and sustainable packaging film?
A: Yes. Another significant advantage of BiONLY is that it is compatible with all existing printing and bag-making equipment, allowing manufacturers to simply convert to sustainable switch socket packaging and switch wall plate packaging without having to make any capital investments in new equipment.
Q: How does the film react during the printing process?
A: BiONLY features constant surface energy properties which provide excellent ink adhesion, and also provides high quality print results, making it suitable for many precision applications within eco-friendly electronic packaging film applications such as switch covers, compostable packaging, switch plate overlays, etc.
Q: Can this film be exported internationally?
A: Yes. BiONLY meets Indian, European and American regulations; therefore, it would be an ideal choice for switch wall plate sustainable packaging and switch socket sustainable packaging that must comply with international export standards.
Q: Is there adhesive required to seal this film?
A: No, in most cases. In addition to being eco-friendly, the film also exhibits superior heat-sealability and, therefore, does not require adhesives. The glue-free sealing feature further adds to the overall value of BiONLY as a clean, eco-friendly electronic packaging film for switches, sockets, and control panel components.
